Blaupunkt DVB-T - Connections Guide; Video and Audio Input Ports; Data, RF, and Accessory Connections; Audio Outputs

34
Connections
Y
L
R
WR
USB
USB-Input
SCART *
SCART-Input
HDMI 1, 2
*, 3* in
HDMI-Input 1, 2*, 3*
CI Card IN
SCART input
VGA(PC) *
VGA PC-Input
COAX Audio Out *
Digital Coax output
RF In
RF / TV Aerial Input
VGA (PC) Audio In *
3.5mm PC audio input
HEADPHONES
3.5mm Headphone
output
R/L - Video & YPbPr
audio In
*
Component / Video audio
input
Video (CVBS) *
VIDEO Input
YPbPr *
Component HD Input
Mini YPbPr *
Mini Component HD
Input
* - optional
R
G
B
Mini Video *
Mini video input and
Audio input rot YPbPr
and Video
