Function compatibility
Incompatible functions
The following function will be inaccessible or deactivated in the cases described below:
Catch on the fly
This is only possible for 2-wire level detection control (tCC = 2C and tCt = LEL or PFO).
This function is locked if automatic injection on stopping is configured as DC (AdC = Ct).
Function compatibility table
The choice of application functions may be limited by the number of I/O and by the fact that some functions are incompatible with one
another. Functions which are not listed in this table are compatible.
If there is an incompatibility between functions, the first function configured will keep the remainder from being configured.
To configure a function, first check that incompatible functions are unassigned, especially those which are assigned in the
factory settings.
(1)Excluding special application with reference channel Fr2.
Priority functions (functions which cannot be active at the same time):
Stop functions have priority over run commands.
Speed references via logic command have priority over analog references.
Summing inputs
(factory setting)
+/- speed (1)
Management of limit switches
Preset speeds
(factory setting)
PI regulator
Jog operation
Brake control
DC injection stop
Fast stop
Freewheel stop
Summing inputs (factory setting)
+/- speed (1)
Management of limit switches
Preset speeds (factory setting)
f
PI regulator
Jog operation
f
f
Brake control
DC injection stop
Fast stop
Freewheel stop
f f
Incompatible functions Compatible functions N/A
f
The function indicated by the arrow has priority over the other.
