Address index
64
Address index
Modbus address CANopen address Code Name Page
3003 2000 / 4 COd Display terminal locking code 56
3006 2000 / 7 LAC Function access level 35
3010 2000 / B ZON Drive type 26
3011 2000 / C NCV Drive rating 26
3012 2000 / D VCAL Drive voltage 26
3015 2000 / 10 bFr Standard motor frequency 28
3017 2000 / 12 INV Nominal drive current 26
3052 2000 / 35 CFG Source configuration 32
3102 2001 / 3 SFr Switching frequency 31
3103 2001 / 4 tFr Maximum output frequency 31
3104 2001 / 5 HSP High speed 27
3105 2001 / 6 LSP Low speed 27
3107 2001 / 8 nrd Noise reduction 31
3110 2001 / B FLr Flying restart (automatic catching a spinning load on ramp) 52
3120 2001 / 15 rPr Operating time reset to zero 55
3201 2002 / 2 ETA Status word 21
3202 2002 / 3 rFr Output frequency applied to the motor (signed value) 21
3203 2002 / 4 FrH Frequency reference before ramp (absolute value) 21
3204 2002 / 8 LCr Current in the motor 21
3205 2002 / 6 Otr Motor torque 21
3206 2002 / 7 ETI Extended status word 22
3207 2002 / 5 ULn Line voltage 21
3209 2002 / A tHd Drive thermal state 21
3210 2002 / B TDM Max. thermal state reached by the drive 21
3211 2002 / C OPr Motor power 21
3231 2002 / 20 rtH Operating time 21
3250 2002 / 33 LRS1 Extended status word No. 1 22
3252 2002 / 35 LRS3 Extended status word No. 3 23
3302 2000 / 4 UdP Drive firmware version 26
3401 2004 / 2 TSP Drive firmware type 26
4434 200E / 23 CrL3 Value for low speed (LSP) on input AI3 33
4444 200E / 2D CrH3 Value for high speed (HSP) on input AI3 33
4601 2010 / 2 AO1t Configuration of the analog output 34
5001 2014 / 2 r1 Relay r1 34
5002 2014 / 3 r2 Relay r2 35
5031 2014 / 20 dO Analog/logic output AOC/AOV 34
5240 2016 / 29 IOLR Value of logic I/O 23
5241 2016 / 2A O1Ct Option board 1 card type 23
5242 2016 / 2B AI1C Value of analog input AI1 23
5243 2016 / 2C AI2C Value of analog input AI2 23
5244 2016 / 2D AI3C Value of analog input AI3 23
5261 2016 / 3E AO1R Value of the analog output 23
6001 201E / 2 Add Modbus: Drive address 55
6003 201E / 4 tbr Modbus: Transmission speed 55
6004 201E / 5 tFO Modbus: communication format 55
6005 201E / 6 ttO Modbus: Time-out 55
6051 201E / 34 AdCO CANopen: Drive address 55
6053 201E / 36 bdCO CANopen: Transmission speed 55
6056 201E / 39 ErCO CANopen: error word 25
7002 2028 / 3 IPL Configuration of line phase loss detection 52
7003 2028 / 4 LFL Stop mode in the event of a loss of 4 - 20 mA signal (LFF) 54
