BLEMO ER23 - Replacing an ER22 with an ER23

57
Replacing an ER2328 with an ER23
If necessary, it is easy to replace an ER22 with a ER23 in an installation communicating via Modbus.
In fact, most of the variables used in the ER22 are found in the ER23 with the same addresses (double addressing).
• To replace an ER22, the ER22 addresses in this table can be used, but only these. All the other ER22 addresses must be replaced
with those for the ER23.
• For any new installation, we recommend using the new addresses, as this enables the number of Modbus requests to be reduced.
(1)See the ER22 communication variables manual.
ER22
address
New
address
Code
ER22
address
New
address
Code
ER22
address
New
address
Code
2 3003 COd 266 11412 SP4 462 7201 DP1
4 4434 CrL3 267 11413 SP5 464 7202 DP2
5 4444 CrH3 268 11414 SP6 466 7203 DP3
6 11101 tCC 269 11415 SP7 468 7204 DP4
10 6001 Add 270 11210 IdC 478 5240 IOLR
40 3015 bFr 272 11701 tLS 482 5261 AO1R
51 3102 SFr 279 11941 rPG 487 3205 Otr
52 3103 tFr 280 11942 rIG 491 3211 OPr
53 9602 FrS 281 11903 FbS 530 3231 rtH
55 9601 UnS 282 11001 Ctd 555 3017 INV
60 3107 nrd 283 11002 ttd 600 8606 ERRD
61 9607 UFt 284 11003 Ftd 601 8601 CMDD
64 9003 brA 286 11301 JPF 602 8603 ETAD
65 9011 Frt 287 11940 PIC 603 8602 LFRD
110 5002 r2 340 64001 rOt 604 8605 FRHD
151 9611 OPL 400 8501 CMD 605 8604 RFRD
152 7002 IPL 401 8502 LFR 606 8607 SMIL
155 3110 FLr 402 8504 CMI 607 8608 SMIL
190 7007 drn 440 11920 rPI 608 8609 SMAL
250 3104 HSP 450 3203 FrH 609 8610 SMAL
251 3105 LSP 451 3202 rFr 610 8611 SPAL
252 9001 ACC 453 3204 LCr 611 8612 SPAL
253 9002 dEC 454 3207 ULn 612 8613 SPAT
258 9622 ItH 455 9630 tHr 613 8614 SPDL
260 9012 AC2 456 3209 tHd 614 8615 SPDL
261 9013 dE2 457 7121 LFt 615 8616 SPDT
262 11111 JGF 458 3201 ETA 991 64003 LCC
264 11410 SP2 459 3206 ETI
265 11411 SP3 460 - ETI2 (1)
