BLEMO ER23 - Control Variables; Drive Control Word Parameters

19
Control variables
Modbus
address
CANopen
address
Code
Read/
Write
Name/Description/Possible values
8501 2037 / 2 CMD R/W Control word
bit 0: "Switch on": active at 1
bit 1: "Disable Voltage": active at 0
bit 2: "Quick Stop": active at 0
bit 3: "Enable Operation": active at 1
bits 4 to 6: Reserved: set to 0
bit 7: Fault state reset: active on rising edge 0 -> 1
bits 8 to 10: Reserved: set to 0
For "Access level" LAC (page 35) = L1 or L2:
bit 11 = 0: Forward direction command
bit 11 = 1: Reverse direction command
bit 12 = 0: No action
bit 12 = 1: Stop command depending on the Stt "Stop type" parameter
bit 13 = 0: No action
bit13 = 1: Injection stop command
bit 14 = 0: No action
bit14 = 1: Fast stop command
bit 15: Reserved: set to 0
For "Access level" LAC (page 35) = L3:
Factory assignments
bit 11 = 0: Forward direction command
bit 11 = 1: Reverse direction command
bit 12 = 0: No action
bit 12 = 1: Stop command depending on the Stt "Stop type" parameter
bit 13: No action
bit 14: No action
bit 15: No action
Bits 11 to 15 can be assigned to the following functions:
Ramp switching (rPS)
Fast stop (FSt)
DC injection (DCI)
2 preset speeds (PS2)
4 preset speeds (PS4)
8 preset speeds (PS8)
16 preset speeds (PS16)
2 preset PI references (Pr2)
4 preset PI references (Pr4)
Switching for 2nd current limit (LC2)
Switching, motor 2 (CHP)
External fault (EtF)
For example, to use bit 15 to switch the ramp, simply set the "Ramp switching" rPS
configuration parameter (page 39) to Cd15.
8502 2037 / 3 LFr R/W Frequency reference via the bus (signed value)
Unit:
• 1 = 0.1 Hz if bit 9 of CMI (page 20) = 0
• 1 ≈ 0.018 Hz (resolution 32767 points = 600 Hz) if bit 9 of CMI = 1
8503 2037 / 4 PISP R/W PI regulator reference via the bus
Unit: 0.1%
Adjustment range: 0 to 1000
