35
Configuration and adjustment variables
Modbus
address
CANopen
address
Code
Read/
Write
Name/Description/Possible values
5002 2014 / 3 r2 R/WS Relay r2
Factory setting: 0
0 = "nO": Not assigned
1 = "FLt": Drive detected fault
2 = "rUn": Drive running
4 = "FtA": Frequency threshold reached (Ftd parameter page 28)
5 = "FLA": High speed (HSP) reached
6 = "CtA": Current threshold reached (Ctd parameter page 28)
7 = "SrA": Frequency reference reached
8 = "tSA": Motor thermal threshold reached (ttd parameter page 28)
9 = "bLC": Brake sequence (for information, as this assignment can be only be activated or
deactivated via the bLC parameter page 47)
12 = "APL": Loss of 4-20 mA signal, even if LFL = nO (page 59)
129 = "LI1": Returns the value of LI1.
130 = "LI2": Returns the value of LI2.
131 = "LI3": Returns the value of LI3.
132 = "LI4": Returns the value of LI4.
133 = "LI5": Returns the value of LI5.
134 = "LI6": Returns the value of LI6.
The relay is energized when the selected assignment is active, with the exception of FLt
(energized if the drive has not detected a fault).
3006 2000 / 7 LAC R/WS Function access level
DANGER
UNINTENDED EQUIPMENT OPERATION
Assigning LAC to L3 will restore the factory settings of the Fr1 (below), Cd1 (page 37),
CHCF (page 36), and tCC (page 33) parameters.
L3 can only be restored to L2 or L1 and L2 to L1 by means of a "factory setting" via FCS
(page 32) or by setting bit 0 of CMI to 1 (page 20).
Check that this change is compatible with the wiring diagram used.
Failure to follow these instructions will result in death or serious injury.
Factory setting: 0
0 = "L1": Access to standard functions. Significantly, this level is interchangeable with ER2328.
1 = "L2": Access to advanced functions:
- +/- speed (motorized potentiometer)
- Brake control
- Switching for second current limit
- Motor switching
- Management of limit switches
2 = L3: Access to advanced functions and management of mixed control modes.
8413 2036 / E Fr1 R/WS Configuration reference 1
Factory setting:
1 = "AI1": Analog input AI1
2 = "AI2": Analog input AI2
3 = "AI3": Analog input AI3
16 = "AIV1": Potentiometer
If LAC = L2 or L3, the following additional assignments are possible:
160 = "UPdt": (1) + speed/- speed via LI. See configuration page 45.
161 = "UpdH": (1) + speed/- speed using the jog dial. For operation, display the frequency rFr
(see page 21.) The +/- speed function via jog dial is controlled from the SUP- menu by setting to
parameter rFr.
If LAC = L3, the following additional assignments are possible:
163 = "LCC": Reference via the remote display terminal, LFr parameter in the SEt- or SUP-
menu.
164 = "Mdb": Reference via Modbus
167 = "nEt": Reference via CANopen
