Code index
59
EP4 7214 202A / F Status of past detected fault No. 4 25
EPL 7006 2028 / 7 Stop mode in the event of an external fault EPF 52
ErCO 6056 201E / 39 CANopen: error word 25
ERRD 8606 603F Fault code 17
ETA 3201 2002 / 2 Status word 21
ETAD 8603 6041 IEC 61800-7 status word 17
EtF 7131 2029 / 20 External fault 52
ETI 3206 2002 / 7 Extended status word 22
FbS 11903 2059 / 4 PI feedback multiplication coefficient 46
FCS 8002 2032 / 3 Return to factory settings/Restore configuration 32
FLG 9620 2042 / 15 Frequency loop gain 27
FLG2 9720 2043 / 15 Frequency loop gain, motor 2 50
FLO 8431 2036 / 20 Forced local mode 55
FLOC 8432 2036 / 21 Selection of the reference and control channel in forced local mode 55
FLr 3110 2001 / B Flying restart (automatic catching a spinning load on ramp) 52
Fr1 8413 2036 / E Configuration reference 1 35
Fr2 8414 2036 / F Configuration reference 2 36
FrH 3203 2002 / 4 Frequency reference before ramp (absolute value) 21
FRHD 8605 6043 Speed reference (signed ramp input) 17
FrS 9602 2042 / 3 Nominal motor frequency given on the rating plate 29
FrS2 9702 2043 / 3 Nominal motor frequency (motor 2) given on the rating plate 49
Frt 9011 203C / C Ramp switching threshold 39
FSt 11204 2052 / 5 Fast stop via logic input 40
Ftd 11003 2050 / 4 Motor frequency threshold 28
HSP 3104 2001 / 5 High speed 27
Ibr 10006 2046 / 7 Motor current threshold for brake release 47
IdC 11210 2052 / B Level of DC injection braking current activated via logic input or selected
as stop mode
40
InH 7125 2029 / 1A Fault detection inhibition assignment 54
Inr 9020 203C / 15 Ramp increment 38
INV 3017 2000 / 12 Nominal drive current 26
IOLR 5240 2016 / 29 Value of logic I/O 23
IPL 7002 2028 / 3 Configuration of line phase loss detection 52
ItH 9622 2042 / 17 Motor thermal protection - max. thermal current 27
JF2 11302 2053 / 3 2nd skip frequency 28
JGF 11111 2051 / C Jog operation reference 45
JOG 11110 2051 / B Jog operation 45
JPF 11301 2053 / 2 Skip frequency 27
LAC 3006 2000 / 7 Function access level 35
LAF 11601 2056 / 2 Forward limit switch 50
LAr 11602 2056 / 3 Reverse limit switch 50
LAS 11603 2056 / 4 Type of limit switch stop 50
LC2 9202 203E / 3 Switching for second current limit 48
LCC 64003 2262 / 4 Control via remote display terminal 38
LCr 3204 2002 / 8 Current in the motor 21
LEt 7090 2028 / 5B Configuration of external fault detection 52
LFD1 8631 2038 / 20 Image of Modbus speed reference 26
LFD2 8632 2038 / 21 Image of CANopen speed reference 26
LFF 7080 2028 / 51 Fallback speed 54
LFL 7003 2028 / 4 Stop mode in the event of a loss of 4 - 20 mA signal (LFF) 54
LFr 8502 2037 / 3 Frequency reference via the bus (signed value) 19
LFR1 8521 2037 / 16 Image of Modbus frequency reference 25
LFR2 8522 2037 / 17 Image of CANopen frequency reference 26
LFRD 8602 6042 Speed reference via the bus (signed value) 16
LFt 7121 2029 / 16 Last detected fault 24
Code Modbus address CANopen address Name Page
