Configuration and adjustment variables
Modbus
address
CANopen
address
Code
Read/
Write
Name/Description/Possible values
9202 203E / 3 LC2 R/WS Switching for second current limit
Factory setting: 0
Function active only if LAC = L2 or L3 (page 35).
Selecting the assigned logic input activates the function.
0 = "nO": Not assigned
129 = "LI1": Logic input LI1
130 = "LI2": Logic input LI2
131 = "LI3": Logic input LI3
132 = "LI4": Logic input LI4
133 = "LI5": Logic input LI5
134 = "LI6": Logic input LI6
If LAC = L3, the following assignments are possible:
171 = "Cd11": bit 11 of the CMD control word (page 19) written by Modbus or CANopen
172 = "Cd12": bit 12 of the CMD control word (page 19) written by Modbus or CANopen
173 = "Cd13": bit 13 of the CMD control word (page 19) written by Modbus or CANopen
174 = "Cd14": bit 14 of the CMD control word (page 19) written by Modbus or CANopen
175 = "Cd15": bit 15 of the CMD control word (page 19) written by Modbus or CANopen
CL1 is enabled when the logic input or control word bit is at state 0 (page 28).
CL2 is enabled when the logic input or control word bit is at state 1 (page 48).
9203 203E / 4 CL2 R/W 2
nd
current limit
Unit: 0.1 A
Factory setting: 1.5 In (1)
Adjustment range: 0.25 to 1.5 In (1)
(1)In corresponds to the nominal drive current indicated in the Installation Manual and on the
drive rating plate.
8011 2032 / C CHP R/WS Switching, motor 2
CAUTION
RISK OF DAMAGE TO THE MOTOR
The motor switching function disables motor thermal protection. An external means of
motor thermal protection must therefore be provided;
Failure to follow these instructions can result in equipment damage
Factory setting: 0
Function active only if LAC = L2 or L3 (page 35).
0 = "nO": Not assigned
129 = "LI1": Logic input LI1
130 = "LI2": Logic input LI2
131 = "LI3": Logic input LI3
132 = "LI4": Logic input LI4
133 = "LI5": Logic input LI5
134 = "LI6": Logic input LI6
If LAC = L3, the following assignments are possible:
171 = "Cd11": bit 11 of the CMD control word (page 19) written by Modbus or CANopen
172 = "Cd12": bit 12 of the CMD control word (page 19) written by Modbus or CANopen
173 = "Cd13": bit 13 of the CMD control word (page 19) written by Modbus or CANopen
174 = "Cd14": bit 14 of the CMD control word (page 19) written by Modbus or CANopen
175 = "Cd15": bit 15 of the CMD control word (page 19) written by Modbus or CANopen
LI or bit = 0: Motor 1
LI or bit = 1: Motor 2
Note:
- If you use this function, do not use the tUn auto-tuning function (page 30) on motor 2 and do
not configure tUn = rUn or POn.
- Changes to parameters are only taken into account when the drive is locked.
