Address index
65
7004 2028 / 5 StP Controlled stop on mains power break 54
7006 2028 / 7 EPL Stop mode in the event of an external fault EPF 52
7007 2028 / 8 drn Derated operation in the event of an overvoltage 54
7008 2028 / 9 OHL Stop mode in the event of the drive overheating OHF 53
7009 2028 / A OLL Stop mode in the event of a motor overload OLF 53
7010 2028 / B SLL Stop mode in the event of a Modbus serial link interuption SLF 53
7011 2028 / C COL Stop mode in the event of a CANopen serial link interuption COF 53
7012 2028 / D tnL Configuration of auto-tuning status tnF 53
7080 2028 / 51 LFF Fallback speed 54
7090 2028 / 5B LEt Configuration of external fault detection 52
7121 2029 / 16 LFt Last detected fault 24
7122 2029 / 17 Atr Automatic restart 51
7123 2029 / 18 tAr Max. duration of restart process 51
7124 2029 / 19 rSF Clearing the current detected fault 51
7125 2029 / 1A InH Fault detection inhibition assignment 54
7128 2029 / 1D rP Reset all the detected faults. 56
7131 2029 / 20 EtF External fault 52
7201 202A / 2 DP1 Past detected fault No. 1 24
7202 202A / 3 DP2 Past detected fault No. 2 24
7203 202A / 4 DP3 Past detected fault No. 3 24
7204 202A / 5 DP4 Past detected fault No. 4 24
7211 202A / C EP1 Status of past detected fault No. 1 25
7212 202A / D EP2 Status of past detected fault No. 2 25
7213 202A / E EP3 Status of past detected fault No. 3 25
7214 202A / F EP4 Status of past detected fault No. 4 25
8001 2032 / 2 SCS Saving the configuration 31
8002 2032 / 3 FCS Return to factory settings/Restore configuration 32
8011 2032 / C CHP Switching, motor 2 48
8401 2036 / 2 CHCF Mixed mode (control channels separated from reference channels) 36
8402 2036 / 3 COP Copy channel 1 to channel 2 37
8411 2036 / C rFC Reference switching 36
8413 2036 / E Fr1 Configuration reference 1 35
8414 2036 / F Fr2 Configuration reference 2 36
8421 2036 / 16 CCS Control channel switching 37
8423 2036 / 18 Cd1 Configuration of control channel 1 37
8424 2036 / 19 Cd2 Configuration of control channel 2 37
8431 2036 / 20 FLO Forced local mode 55
8432 2036 / 21 FLOC Selection of the reference and control channel in forced local mode 55
8501 2037 / 2 CMD Control word 19
8502 2037 / 3 LFr Frequency reference via the bus (signed value) 19
8503 2037 / 4 PISP PI regulator reference via the bus 19
8504 2037 / 5 CMI Extended control word 20
8521 2037 / 16 LFR1 Image of Modbus frequency reference 25
8522 2037 / 17 LFR2 Image of CANopen frequency reference 26
8531 2037 / 20 PIR1 Image of Modbus PI reference 26
8532 2037 / 21 PIR2 Image of CANopen PI reference 26
8541 2037 / 2A CMI1 Image of Modbus extended control word 25
8542 2037 / 2B CMI2 Image of CANopen extended control word 25
8601 6040 CMDD IEC 61800-7 control word 16
8602 6042 LFRD Speed reference via the bus (signed value) 16
8603 6041 ETAD IEC 61800-7 status word 17
8604 6044 RFRD Output speed (signed value) 17
8605 6043 FRHD Speed reference (signed ramp input) 17
8606 603F ERRD Fault code 17
8607 - 8608 6046 / 1 SMIL Min. speed 18
Modbus address CANopen address Code Name Page
