Address index
66
8609 - 8610 6046 / 2 SMAL Max. speed 18
8611 - 8612 6048 / 1 SPAL Acceleration - Speed delta 18
8613 6048 / 2 SPAT Acceleration - Time delta 18
8614 - 8615 6049 / 1 SPDL Deceleration - Speed delta 18
8616 6049 / 2 SPDT Deceleration - Time delta 18
8631 2038 / 20 LFD1 Image of Modbus speed reference 26
8632 2038 / 21 LFD2 Image of CANopen speed reference 26
9001 203C / 2 ACC Acceleration ramp time 39
9002 203C / 3 dEC Deceleration ramp time 39
9003 203C / 4 brA Deceleration ramp adaptation 39
9004 203C / 5 rPt Type of ramp 38
9005 203C / 6 tA1 Start of CUS-type acceleration ramp rounded 38
9006 203C / 7 tA2 End of CUS-type acceleration ramp rounded 38
9007 203C / 8 tA3 Start of CUS-type deceleration ramp rounded 38
9008 203C / 9 tA4 End of CUS-type deceleration ramp rounded 38
9010 203C / B rPS Ramp switching 39
9011 203C / C Frt Ramp switching threshold 39
9012 203C / D AC2 2nd acceleration ramp time 39
9013 203C / E dE2 2nd deceleration ramp time 39
9020 203C / 15 Inr Ramp increment 38
9101 203D / 2 SrF Suppression of the speed loop filter 31
9201 203E / 2 CLI Current limit 28
9202 203E / 3 LC2 Switching for second current limit 48
9203 203E / 4 CL2 2nd current limit 48
9601 2042 / 2 UnS Nominal motor voltage given on the rating plate 28
9602 2042 / 3 FrS Nominal motor frequency given on the rating plate 29
9603 2042 / 4 nCr Nominal motor current given on the rating plate 29
9604 2042 / 5 nSP Nominal motor speed given on the rating plate 29
9606 2042 / 7 COS Motor Cos Phi given on the rating plate 29
9607 2042 / 8 UFt Selection of the type of voltage/frequency ratio 31
9608 2042 / 9 tUn Motor control auto-tuning 30
9609 2042 / A tUS Auto-tuning status 30
9611 2042 / C OPL Configuration of motor phase loss detection 52
9620 2042 / 15 FLG Frequency loop gain 27
9621 2042 / 16 StA Frequency loop stability 27
9622 2042 / 17 ItH Motor thermal protection - max. thermal current 27
9623 2042 / 18 UFr IR compensation/Voltage boost 27
9625 2042 / 1A SLP Slip compensation 27
9630 2042 / 1F tHr Motor thermal state 21
9643 2042 / 2C rSC Cold state stator resistance 29
9701 2043 / 2 UnS2 Nominal motor voltage (motor 2) given on the rating plate 49
9702 2043 / 3 FrS2 Nominal motor frequency (motor 2) given on the rating plate 49
9703 2043 / 4 nCr2 Nominal motor current (motor 2) given on the rating plate 49
9704 2043 / 5 nSP2 Nominal motor speed (motor 2) given on the rating plate 49
9706 2043 / 7 COS2 Motor Cos Phi (motor 2) given on the rating plate 49
9707 2043 / 8 UFt2 Selection of the type of voltage/frequency ratio for motor 2 49
9720 2043 / 15 FLG2 Frequency loop gain, motor 2 50
9721 2043 / 16 StA2 Frequency loop stability, motor 2 50
9723 2043 / 18 UFr2 IR compensation/Voltage boost, motor 2 50
9725 2043 / 1A SLP2 Slip compensation, motor 2 50
10001 2046 / 2 bLC Brake control configuration 47
10002 2046 / 3 brL Brake release frequency 47
10003 2046 / 4 bEn Brake engage frequency threshold 47
10004 2046 / 5 brt Brake release time 47
10005 2046 / 6 bEt Brake engage time 47
Modbus address CANopen address Code Name Page
