Address index
67
10006 2046 / 7 Ibr Motor current threshold for brake release 47
10007 2046 / 8 bIP Brake release pulse 47
10401 204A / 2 AdC Automatic standstill DC injection 41
10402 204A / 3 tdC1 Automatic standstill DC injection time 41
10403 204A / 4 SdC1 Level of automatic standstill DC injection current 41
10404 204A / 5 tdC2 2nd automatic standstill DC injection time 41
10405 204A / 6 SdC2 2nd level of standstill DC injection current 41
11001 2050 / 2 Ctd Motor current threshold 28
11002 2050 / 3 ttd Motor thermal state threshold 28
11003 2050 / 4 Ftd Motor frequency threshold 28
11101 2051 / 2 tCC 2-wire/3-wire control 33
11102 2051 / 3 tCt Type of 2-wire control 33
11105 2051 / 6 rrS Reverse operation via logic input 33
11110 2051 / B JOG Jog operation 45
11111 2051 / C JGF Jog operation reference 45
11201 2052 / 2 Stt Normal stop mode 40
11202 2052 / 3 nSt Freewheel stop via logic input 41
11203 2052 / 4 dCI DC injection via logic input 40
11204 2052 / 5 FSt Fast stop via logic input 40
11210 2052 / B IdC Level of DC injection braking current activated via logic input or selected
as stop mode
40
11211 2052 / C tdC Total DC injection braking time selected as normal stop mode 41
11230 2052 / 1F dCF Coefficient for dividing the deceleration ramp time for fast stopping 40
11301 2053 / 2 JPF Skip frequency 27
11302 2053 / 3 JF2 2nd skip frequency 28
11401 2054 / 2 PS2 2 preset speeds 42
11402 2054 / 3 PS4 4 preset speeds 43
11403 2054 / 4 PS8 8 preset speeds 43
11404 2054 / 5 PS16 16 preset speeds 43
11410 2054 / B SP2 2nd preset speed 44
11411 2054 / C SP3 3rd preset speed 44
11412 2054 / D SP4 4th preset speed 44
11413 2054 / E SP5 5th preset speed 44
11414 2054 / F SP6 6th preset speed 44
11415 2054 / 10 SP7 7th preset speed 44
11416 2054 / 11 SP8 8th preset speed 44
11417 2054 / 12 SP9 9th preset speed 44
11418 2054 / 13 SP10 10th preset speed 44
11419 2054 / 14 SP11 11th preset speed 44
11420 2054 / 15 SP12 12th preset speed 44
11421 2054 / 16 SP13 13th preset speed 44
11422 2054 / 17 SP14 14th preset speed 44
11423 2054 / 18 SP15 15th preset speed 44
11424 2054 / 19 SP16 16th preset speed 44
11501 2055 / 2 USP + speed (motorized potentiometer) 45
11502 2055 / 3 dSP - speed (motorized potentiometer) 45
11503 2055 / 4 Str Save reference 45
11601 2056 / 2 LAF Forward limit switch 50
11602 2056 / 3 LAr Reverse limit switch 50
11603 2056 / 4 LAS Type of limit switch stop 50
11701 2057 / 2 tLS Low speed operating time 28
11801 2058 / 2 SA2 Summing input 2 42
11802 2058 / 3 SA3 Summing input 3 42
11901 2059 / 2 PIF PI regulator feedback 45
11903 2059 / 4 FbS PI feedback multiplication coefficient 46
Modbus address CANopen address Code Name Page
