Configuration and adjustment variables
(1)Note: The "Preset speeds" function may be incompatible with other functions (see page 14).
Modbus
address
CANopen
address
Code
Read/
Write
Name/Description/Possible values
11801 2058 / 2 SA2 R/WS Summing input 2
Note The "Summing inputs" function may be incompatible with other functions (see page 14).
Factory setting: 2
Can be used to sum one or two inputs to reference Fr1 only.
0 = "nO": Not assigned
1 = "AI1": Analog input AI1
2 = "AI2": Analog input AI2
3 = "AI3": Analog input AI3
16 = "AIV1": Potentiometer
If LAC = L3, the following assignments are possible:
163 = "LCC": Reference via the remote display terminal, LFr parameter in the SEt- or SUP-
menu.
164 = "Mdb": Reference via Modbus
167 = "nEt": Reference via CANopen
11802 2058 / 3 SA3 R/WS Summing input 3
Note The "Summing inputs" function may be incompatible with other functions (see page 14).
Factory setting: 0
Can be used to sum one or two inputs to reference Fr1 only.
0 = "nO": Not assigned
1 = "AI1": Analog input AI1
2 = "AI2": Analog input AI2
3 = "AI3": Analog input AI3
16 = "AIV1": Potentiometer
If LAC = L3, the following assignments are possible:
163 = Reference via the remote display terminal, LFr parameter in the SEt- or SUP- menu.
164 = "Mdb": Reference via Modbus
167 = "nEt": Reference via CANopen
11401 2054 / 2 PS2 R/WS 2 preset speeds
Factory setting: if tCC = 1: 0 if tCC = 0 or 2: 131
Selecting the assigned logic input activates the function (1).
0 = "nO": Not assigned
129 = "LI1": Logic input LI1
130 = "LI2": Logic input LI2
131 = "LI3": Logic input LI3
132 = "LI4": Logic input LI4
133 = "LI5": Logic input LI5
134 = "LI6": Logic input LI6
If LAC = L3, the following assignments are possible:
171 = "Cd11": bit 11 of the CMD control word (page 19) written by Modbus or CANopen
172 = "Cd12": bit 12 of the CMD control word (page 19) written by Modbus or CANopen
173 = "Cd13": bit 13 of the CMD control word (page 19) written by Modbus or CANopen
174 = "Cd14": bit 14 of the CMD control word (page 19) written by Modbus or CANopen
175 = "Cd15": bit 15 of the CMD control word (page 19) written by Modbus or CANopen
