Blodgett CTB Replacement Parts List

JANUARY 12, 2012 2 CTB/CTBR
 Doors Are Not Returnable
IMPORTANT: When ordering parts, please provide the
model, voltage and serial number of the oven. The
identication plate is located above the control panel
under the ledge.
ELECTRICAL COMPONENTS
Ref. Part
No. No. Description
1 20350 Buzzer, Electric 240V
2 18868 Mode Selector Switch w/o Knob, 1 SP
21068 Mode Selector Switch w/o Knob, 2 SP
3 16686 Knob, Mode Selector Switch
4 30465 Cool Down Switch, Rocker SPDT
Matt Black
5 16037 Indicator Light, 250V, Red, Round
16605 Fuse, 10 AMP(Before 6/88 and after1/97)
6 20162 Fuse, 10 AMP (Between 6/88 and 01/20/97)
20442 Fuse Holder (After 01/20/97)
7 20163 Fuse Holder (Between 6/88 and 01/20/97)
16604 Fuse Holder (Before 6/88)
8 32313 Motor, 230V, 1 PH, 1/4 HP, 1 SP
8 32302 Motor, 230V, 1 PH, 1/4 HP, 2 SP
9 6138 Blower Wheel Assy., (8-1/2" Diameter)
10 11204 Terminal Block w/ Screws
4888 Lug, Grounding
34898 Cord Set Assy. w/receptacle, 3 PH
34899 Cord Set Assy. w/receptacle, 1 PH
37227 Harness, Element 5 KW
16647 Harness, Element 7.5 KW
11 19118 Element Assy., 208V, 5 KW
11 8596 Element Assy., 230V, 5 KW
11 8595 Element Assy., 240V, 5 KW
19284 Element Assy., 208V, 7.5 KW
90097 Element Assy., 230V, 7.5 KW
90098 Element Assy., 240V, 7.5 KW
NOTE: 2 Element Rings in element assy = 5 KW
3 Element Rings in element assy = 7.5
KW
6177 Microswitch Plate (used with 16880)
12 16880 Microswitch Assy., Door (Before 02/14/97)
33946 Microswitch Assy., Door (After 02/14/97)
33286 Activator, Door Switch (Before 07/17/98)
used with 33946
34524 Activator, Door Switch (07/17/98 and After)
used with 33946
13 21430 Axial Fan Kit, 3", 230V (Before 05/22/97 or
S.N. 052297LA035S)
13 23034 Axial Fan Kit, 4", 230V (After 05/22/97 or
S.N. 052297LA035S)
14 37296 Mechanical Contactor Conversion Kit,
(1&3PH)
R11087 Mechanical Contactor, 3 Pole,40 AMP,240V,
(1 & 3PH)
NOTE: Contactors listed above for 5 kW or 7.5
KkW ovens.
36429 Circuit Breaker
CONTROLS FOR OVENS
MANUFACTURED BEFORE 7/83
Ref. Part
No. No. Description
5147 Timer, 60 Minute Mechanical w/ Knob
16498 Knob, Timer 60 Minute Mechanical
11304 Dial, 60 Minute Mechanical Timer
16948 Timer, 60 Minute for Electric Buzzer w/ Knob
16820 Dial Plate
16030 Knob, 60 Minute Timer for Electric Buzzer
5279 Thermostat, KX-38-36 w/o Knob
(140º - 550º)
11224 Dial, Thermostat
6502 Cool Down Switch, Rocker DPDT, Red
6500 Blower Switch, Rocker DPST, Blue
6504 Indicator Light, 250V, Red, Rectangular
CONTROLS FOR OVENS
MANUFACTURED
7/83 THROUGH 9/86
Ref. Part
No. No. Description
15956 Timer, 60 Minute w/o Knob (Cook Only)
16030 Knob, Timer
16536 Thermostat, Cook KX-234-36 w/o Knob
(140º - 500º)
17212 Knob, Thermostat
90588 Contactor, 50 AMP
16607 Control Decal, Lexan (Cook Only)
