Installation
14
Electrical Connection
Wiring diagrams are located in the control
compartment and on the back of the oven.
This oven is supplied for connection to 115 volt
grounded circuits. The electric motor, indicator
lights and related switches are connected through
the 6’ electric supply cord found at the rear of the
oven.
WARNING!!
This appliance is equipped with three
pronggroundingtypeplugforyour
protection against shock hazard and
shouldbe plugged directly into a properly
ground ed three prong receptacle. DO
NOT cut or remove the grounding prong
from this plug.
THE BLODGETT OVEN COMPANY CANNOT AS-
SUME RESPONSIBILITY FOR LOSS OR DAMAGE
SUFFERED AS A RESULT OF IMPROPER INSTAL-
LA TION.
ELECTRICAL SPECIFICATIONS
Model Hz Volts Phase Amps Electrical Connection
(minimum size)
U.S. and Canadian Installations
DFG-100-3 60 115 1 6 Cord set provided
DFG-200-L 60 115 1 6 Cord set provided
Australia and General Export Installations
DFG-100-3 50 220-240 1 3 Size per local code
DFG-200-L 50 220-240 1 3 Size per local code
