Blodgett Mark V Replacement Parts List

FAN DELAY WITH PULSE PLUS
Ref. Part
No. No. Description
18291 Timer, Fan Delay, 10 Minute, 240V
18293 Timer, Fan On, 30 Minute, 240V
18583 Timer, Solid State, Pulsing, 30 Second, 240V
16539 Indicator Light, 250V, Amber, Round
18582 Relay, 3PDT, 240V w/ Bracket
18355 Harness, control wiring
8 Set Point or Infinite, 2 SP
18679 Control Panel & Decal, Porcelain, Infinite
18277 Control Panel & Decal, Porcelain, 8 Set Pt.
16686 Knob
COOK & HOLD CONTROLS
Ref. Part
No. No. Description
17984 Timer, 12 Hour w/ Knob (Before 2/25/85)
17863 Timer, 12 Hour w/o Knob (After 2/25/85)
3 16686 Knob, Timer
15365 Thermostat, Hold K-877-36 w/o Knob
(120º - 200º)
16392 Knob, Thermostat
20351 Controller, Temperature Hold (150º - 250º)
3 16686 Knob, Temperature Hold Controller
15 18588 Probe, Temperature
18234 Potentiometer
2 18868 Selector Switch w/o Knob, Mode
(3 Positions) (Before 1/18/85)
20347 Selector Switch w/o Knob, Mode
(4 Positions) (After 1/18/85)
3 16686 Knob, Mode Selector Switch
16539 Indicator Light, 250V, Amber, Round
Hold Only
19666 Relay, Motor, 25 Amp., DPDT, 240V
18780 Harness, Wiring (1 SP)
18870 Harness, Wiring (2 SP)
16779 Control Panel Decal (Before 6/1/84)
17262 Control Panel & Decal, Porcelain,
1 SP & 2 SP (Between 6/1/84 and 1/8/85)
17907 Control Panel & Decal, Porcelain, 1 SP
(Between 1/8/85 and 8/86)
17908 Control Panel & Decal, Porcelain, 2 SP
(Between 1/8/85 and 8/86)
18746 Control Panel & Decal, Porcelain, 1 SP
(After 8/86)
18747 Control Panel & Decal, Porcelain, 2 SP
(After 8/86)
SOLID STATE MANUAL CONTROLS
STANDARD ON OVENS MANUFACTURED
AFTER 7/86
Ref. Part
No. No. Description
14 18578 Control Board, Solid State Temperature
15 18588 Probe, Temperature
16 18234 Potentiometer, Remote (Infinite Control)
18577 8 Position Temperature Switch
(Specify Model & Temperature Settings)
3 16686 Knob, 8 Position Temperature Switch
17 18226 Timer, 60 Minute 240V
3 16686 Knob, 60 Minute Timer
19428 Timer, 6 Hour 240V
19518 Dial, 6 Hour Timer
30518 Momentary Switch
30517 Blower Switch, Hi / Low
18352 Harness, Wiring (8 Set Point or Infinite,
(1 SP)
18351 Harness, Wiring (8 Set Point or Infinite,
(2 SP)
18283 Control Panel & Decal, Infinite, 1 SP
18281 Control Panel & Decal, Infinite, 2 SP
18280 Control Panel & Decal, 8 Set Point, 1 SP
18278 Control Panel & Decal, 8 Set Point, 2 SP
SOLID STATE DIGITAL CONTROLS
5 KEY
Ref. Part
No. No. Description
19 30658 Controller, Solid State Digital
FW529 Controller, Reconditioned
15 18588 Probe, Temperature
24684 Knob, Mode (For 30658)
24685 Knob, Adjust
2 18868 Selector Switch w/ Knob, Mode (3 Positions)
1 SP
21068 Selector Switch w/ Knob, Mode (4 Positions)
2 SP
3 16686 Knob, Mode Selector Switch
30662 Light Switch, Momentary
23086 Suppressor Assy., RC
24924 Harness, Wiring (1 SP)
24920 Harness, Wiring (2 SP)
30666 Control Panel & Decal, 1 SP
30667 Control Panel & Decal, 2 SP
21439 Control Cover Assy.
4 MARK V

Blodgett Mark V Specifications

General

Model	Mark V
Manufacturer	Blodgett
Category	Oven
Temperature Range	200°F - 500°F (93°C - 260°C)
Construction	Stainless Steel
