Blodgett ZEPHAIRE-G Replacement Parts List

ZEPHAIRE G
JULY 26, 2007
; ASAP Distributor Required Stocking Parts
 Doors Are Not Returnable
* Item Is Too Large For UPS
IMPORTANT: When ordering parts, please provide the model, gas type
and serial number of the oven. The identification plate is located on
the left side of the combustion compartment and, also, above the control
panel under the ledge.
2
ELECTRICAL COMPONENTS
(SOLID STATE CONTROLS)
(AFTER 07/12/93)
Ref. Part
No. No. Description
8 32232 Motor, 115V, 1 PH, 1/3 HP, 1 SP
32291 Motor, 115V, 1 PH, 1/3 HP, 2 SP
23077 Capacitor, Motor 2 SP
20362 Conduit Assy., Motor 1 SP
20065 Conduit Assy., Motor 2 SP
1 20349 Buzzer, 120V
9 18225 Timer, 60 Minute, 120V, 60 HZ
6 16686 Knob, Timer
33152 Temperature Controller w/ Potentiometer
13 18588 Probe, Temperature
16686 Knob, Thermostat
3 20355 Transformer, 115V to 24V
10 20348 Spark Box Assy, LP & Nat (G770MGC-Blue)
7 21134 Axial Fan, Low Velocity, 115 V, 60HZ (Qty 2)
14 35702 Microswitch Kit (Replaces 19978)
35419 Bracket Assy., Microswitch
(Replaces 21081)
5091 Cord Set Assy
4 6502 Cool Down Switch, Rocker DPDT Red
4 6500 Blower Switch, Rocker DPST Blue 1 SP
7636 Blower Switch, Rocker 3PDT Black 2 SP
4 6497 Light Switch, Rocker SPST Matte Black
2 18265 Indicator Light, 28V, Red, Round
4342 Lamp
4922 Socket, Lamp
15891 Tube Assy, for lamp
ELECTRICAL COMPONENTS
(MECHANICAL CONTROLS)
(PRIOR TO 07/12/93)
Ref. Part
No. No. Description
8 32232 Motor, 115V, 1 PH, 1/3 HP, 1 SP
8 32291 Motor, 115V, 1 PH, 1/3 HP, 2 SP
20362 Conduit Assy., Motor 1 SP
20349 Buzzer, 120V
19 5147 Timer, 60 Minute Mechnical, w/bell
15956 Timer, for Buzzer
16030 Knob, Timer
23 16536 Thermostat, KX-234-36
16393 Dial, Thermostat
21082 Bracket Assy., Thermostat
20195 Gauge, Spark Gap
35702 Microswitch Kit (Replaces 19978)
35419 Bracket Assy., Microswitch
(Replaces 21081)
5091 Cord Set Assembly
6502 Cool Down Switch, Rocker DPDT Red
6500 Blower Switch, Rocker DPST Blue
6497 Light Switch, Rocker SPST White
15673 Indicator Light, 125V, Red, Round
4342 Lamp
4922 Socket, Lamp
15891 Tube Assy, for lamp
20361 Wiring Harness, 115V, 1 SP
21593 Wiring Harness, 115V, 2SP

Blodgett ZEPHAIRE-G Specifications

General

Pan Size	18" x 26"
Temperature Range	200°F to 500°F
Controls	Solid State
Configuration	Single Deck
Construction	Stainless steel front, top, and sides
Warranty	1 year parts and labor
