DRIVERS HANDBOOK
Left Switch Console
The left switch console under the driver’s
side window shown here consists of the Ra-
dio Switch Panel, the Heater Control Panel,
Right and left rearview mirror controls, up-
per and lower switch banks, an optional
storage compartment, the optional PA mic
jack and a 12 volt auxiliary jack.
The left switch console contains three
switch panel banks. The exact arrangement
of switches in all switch panels is somewhat
dependent upon specific state specifica-
tions. (For example, some states require ad-
ditional switches for red and amber Warn-
ing Light pilots.) Shown are the standard
and most common configurations. If your
bus differs from the diagrams shown, check
with your local specifications and familiar-
ize yourself with each switch function.
12 Volt Auxiliary Jack
Right & Left Mirror Controls
PA Mic Jack
Lower Switch Panel
Heater Control Panel
Upper Switch Panel
Radio Switch Panel
