Blue Box SIGMA 2002 - Page 10

Blue Box - 4
SERIES
The SIGMA 2002 series of water cooled chillers, for installation inside the building, are available in various sizes
with capacities from 42 to 297 kW.
Model designations consist of two numbers:
SIGMA 2002 16.4
Shows the model number of compressors
The model, serial number, characteristics, power supply, etc. are shown by means of decals on the unit.
