En - 8
• To release the hose from the spray gun, press the blue
button on the underside of the gun toward the trigger
guard. The hose will slide out from the connection.
Spray Gun
• To lock the trigger of the spray gun aim the gun away
from you and push the lock button from right to left, (Fig.
7), after doing so, squeeze or pull the trigger to make sure
it is locked and will not move. Get in the habit of leaving
the lock button in the “locked” position when the power
washer is not in use. This ensures the gun is in “safe”
mode until it is ready for use.
Lance and Detergent bottle
• While the spray gun is in the locked position, insert
the turbo lance, the adjustable spray lance, or the
detergent bottle directly into the end of the spray gun
by inserting and pushing together and turning clockwise
simultaneously. To remove push together and turn counter
clockwise (Fig. 8). Push the safety lock button to lock the
trigger when changing lances or detergent tank, to ensure
that they do not accidentally eject with force during
removal.
• When using the turbo lance, make sure the turbo nozzle
is screwed on tight at the end of the lance, each time
you use it. The Turbo lance is designed for high impact
cleaning. Only use on hard surfaces such as driveways,
cement surfaces, patio bricks, etc. A test strip should be
done prior to avoid chance of damaging the surface.
• When using the adjustable spray lance, the spray pat-
tern and intensity can be controlled according to power of
water needed for each task by twisting the spray nozzle
at the far end of the lance (Fig. 9). These can be used for
sweeping leaves or debris from at surfaces or curbing.
This lance has the widest variety of applications as the
fan degree allows for good impact pressure and cleaning
coverage.
• When using the detergent bottle, * ll it with a properly
formulated detergent or cleaner with water ratio according
to instructions on the container (Fig. 10). The detergent
bottle comes with a straw which is tted into the screw-on
top. If you don’t see the straw, look inside the bottle and
attach it to the screw-on top (Fig. 11).
* Note: the ratio of water to detergent is 10:1 or 10 parts
water to 1 part detergent.
Garden Hose Adapter
• Install the garden hose adapter (GHA) and quick connect
lter. It is made up of two separate pieces. (1) A clear
plastic adapter with a screen lter (about 3 inches long)
and (2) a blue/black collar attachment (Fig. 12).
• First, remove the plastic shipping cover on the water
inlet on the front of the power washer. Attach the clear
plastic adapter by screwing it into the water inlet (Fig.
13). Hand tight is ne. Next screw on the blue/black collar
attachment to your garden hose (Fig. 14). Slide the blue/
Fig. 7
Gun
Safety
Button
Trigger
Gun
QC - Clear
Adapter
Garden Hose
Adapter (GHA)
(GHA)
Fig. 8
Fig. 10
Fig. 11
Fig. 9
Fig. 12
Fig. 13 Fig. 14
