Blue Clean AR112 - QUICK START; Total Stop System (TSS) Explanation

3
1. Insert lance adapter into the gun by pushing together and turning clockwise
to a positive stop. Remove the same way by pushing together and turning
counter-clockwise.
2. Press release button on bottom of gun toward back of the gun, then insert
high pressure hose.
3. 
clear plastic adapter by screwing it into the water inlet on the back of the ma-
chine, screw the blue/black collar attachment to your garden hose. Slide the
GHA onto the clear adapter.
4. Attach the high pressure hose onto the pump water outlet by turning clock-
wise and hand tightening on the front of the machine.
5. Activate the lock by holding the gun and push the lock from left to right.
Squeeze trigger to make sure the trigger does not move. The safety trigger
lock should be locked at all times when power washer is not in use.
6. Plug the power cord into a grounded 120V outlet and press the reset button
as shown, this must be done each time the unit is plugged in.
7. Press to (-) for on Press (o) for off.
IMPORTANT



automatically turns the motor off to protect the pump from overheating.
Pump
Hose
Garden
Hose
Adapter
Pump
High Pressure Hose
2
Trigger
Safety Lock
1
Reset
On
O
1
2
3
4
6
7
5
QUICK START
