ASSEMBLY OF THE RESIN TOP PLATFORMS
• Place a resin top platform over a metal plate and attach using four bolts, continue this process until
all the resin top platforms are attached to all the metal plates at the top (see diagram 31)
• Check the alignment, but do not tighten.
• Adjust the distance between the two metal plates if necessary to accommodate the top platforms.
Once the platforms are in position, line up the screw holes and lightly fasten with the bolts provided.
CAUTION: Fix all resin top platforms to the metal plate at the top and make sure they are all sitting
properly before nally tightening the screws.
ASSEMBLY OF THE JOINT PROTECTORS
• The joint protectors are for covering and protecting the edges of the resin top platform. Hook the
joint protector over the inside edge of the resin top platforms and gently pull to fasten the cover to
the outside edge. Fix with the screws provided (see diagrams 32, 33, and 34).
Make sure that the resin top platform is placed
with the curved edge outside the pool.
(Diagram 31)
(Diagram 32) (Diagram 33) (Diagram 34)
