Blue Wave SAVANNAH - Savannah Oval Style Pool - Parts List

7
SAVANNAH OVAL STYLE POOL - PARTS LIST (Not to scale)
Check all parts and ensure they are present and undamaged before assembly. Images and objects
may differ. Report missing or damaged parts immediately to have them replaced. For damaged or
replacement parts, contact Blue Wave
®
Customer Service at (800)759-0977.
# BW No. Parts Description MFG No.
30-ft x 15-ft x 52-in
1
NBP6045 POOL WALL 30191001 1
2
NBP6046 RESIN TOP PLATFORM 30191005 12
3
NBP6047 RESIN SIDE TOP PLATFORM 30191006 4
4
NBP6037 RESIN VERTICAL SUPPORT 20181008 16
5 NBP6048
RESIN BOTTOM RAIL 30191009 16
6 NBP6049
COPING 30191010 16
7 NBP6050 RESIN ROUND RAIL 30191011 16
8 NBP6033 PROTECTIVE PLUG 20181005 16
9
NBP6034 JOINT PROTECTOR 20181006 16
10
NBP6035 METAL PLATE 20181007 26
11 NBP6036 SELF-ADHESIVE TAPE 20001021 1
12 NBP6038 M6 NUT 20001022 58
13 NBP6039 M6 WASHER 20001026 58
14 NBP6040 M6X11 BOLT 20001023 138
15 NBP6041 M4X10 BOLT 20001024 78
16 NBP6051 L MODEL SUPPORT 30191021 6
17 NBP6052 FIXED PLATE 30191022 6
18 NBP6053 CONNECTION FIXED PLATE 30191023 3
19 NBP6054 M12-NUT 30191024 24
20 NBP6055 M12-WASHER 30191025 24
21 NBP6056 M12x24-BOLT 30191026 12
22 NBP6057 M12x100-BOLT 30191027 12
