Bluewater CLEONE - System Overview; Clean Water Tank

07
© Bluewater Group 2016
SYSTEM OVERVIEW
Figure 5.
6
5
4
3
2
1
System overview
Pos Description Pos Description
1 Cleone water purifier 4 Feed water connection
2 Power adapter 5 Drain water connection
3 Clean water tank 6 Clean water faucet
Clean water tank
Figure 6.
10
Clean water tank valve
Pos Description
0 Valve closed – no water can flow
1 Valve open – water can flow to and from the tank
