BLUM Aventos HK-S User Manual

Subject to technical modifications without notice. © 2015
5
Place the left and right cover plates over the appropriate lift mechanisms and snap them in place.
Use a POZI screwdriver on cam adjustments for each of the three 3-dimensional adjustments.
7
Finalize the door adjustments
8
Attach cover caps
± 2 mm
± 2 mm
± 2 mm

BLUM Aventos HK-S Specifications

General

Opening Angle	107°
Power Factor Range	Not applicable
Type	Lift System
Application	Wall cabinets
Adjustment	3-dimensional adjustment
Material	Steel
Color	Light gray (RAL 9006)
