Subject to technical modifications without notice. © 2015
4
Use a screw gun, POZI driver bit insert and bit holder to adjust each lift mechanism to the
desired tension.
Attach the door using the CLIP mechanism in the mounting plate.
5
Attaching the door
6
Adjust the door tension
2
Assembly

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the BLUM Aventos HK-S and is the answer not in the manual?

BLUM Aventos HK-S Specifications

General IconGeneral
Opening Angle107°
Power Factor RangeNot applicable
TypeLift System
ApplicationWall cabinets
Adjustment3-dimensional adjustment
MaterialSteel
ColorLight gray (RAL 9006)
