Electrical connection
3. Electrical connection
NOTICE
Damage and malfunction of the measuring system is possible caused by faulty cable
mounting
Connect or disconnect connecting cables or plug connections without power sup-
ply only.
Observe fail-safe cable laying according to the regulations for measuring system ca-
bles.
Connect the cable shielding on the control side with the machine earth. At adapter
connections the shielding must be directed over the plug housing and the com-
plete plug connection must be mounted isolated.
Observe intactness of gasket and adjusting groove of plug connector.
Tighten the plug connector firmly (M
d
= 2.0 ... 2.5 Nm).
NOTICE
Damage to the measuring system by short circuit possible.
The outputs cannot be connected in parallel!
Connect each individual wire to its own terminal.
NOTICE
Damage by improper installation of cables and hoses
When mounting cables and hoses, please provide sufficient strain relief.
Please note the minimum binding radius of cables and hoses.
