Configuration
4.3 Electrical connection
X1
Pin Connection Designation Data
1 GND Mass 0 V
2 24 V Power supply U
B
15 ... 30 V / 100 mA
3 TC Mode TC 10 ... 30 V / 10 mA
4 DUO Mode DUO 10 ... 30 V / 10 mA
5 START Flash / Start 10 ... 30 V / 10 mA
6 BG Mode BG 10 ... 30 V / 10 mA
7 TWIN Mode TWIN 10 ... 30 V / 10 mA
8 Batt Output
BATTERY 24 V / 50 mA
9 Stat1 Output STATUS1 24 V / 50 mA
10 Stat1 Output STATUS1 24 V / 50 mA
11 Error Output
ERROR 24 V / 50 mA
12 Stat2 Output STATUS2
Solid State Relay (SSR)
13
14 AUX Input AUX 10 ... 30 V / 10 mA
15 GND Mass 0 V
To Next Page
