BLUM IF59-A2 User Manual

V3A | 08/2018
22
© by Blum-Novotest
Electrical connection
3.3 Electrical connection IF59-A2 and laser system / Z-Nano on one mea-
suring input
Fig. 3-7
a)
DIP switch 2:
If SW3 is in position ON, the outputs in standby mode are also switched with
level high/low.
IF59
PLC
Y *.*
a)
1 2 3 4 5 6 7 8 9 1011 1213 1415
1 2 3 4
ON
1 2 3 4
ON
DYNAMIC (GN)
EN0, EN1, EN2
STATUS (YE)
STATUS (GY)
or
1 2 3 4
ON
1 2 3 4 5 6 7 8 9 10
ON
1 2 3 4
ON
5 6 7 8 9 10
1 2 3 4
ON
1 2 3 4
ON
1 2 3 4
ON
