Electrical connection
NOTICE
Measuring system malfunctioning and damage possible as a result of faulty earthing.
Use the enclosed BLUM accessory set!
Earth the measuring system as per the installation instructions for the accessory
set!
NOTICE
Material damages caused by wrong wiring of the interfaces at the machine control
The electrical connections, mentioned in this instruction, are exemplary and may vary
depending on the machine control.
Please refer to the documentation supplied by the machine manufacturer!
Consider the electrical wiring diagrams, suitable for your machine control!
NOTICE
Measuring error is possible.
If the signals BATTERY and ERROR are not monitored, measuring errors may occur.
Carry out multiple contacts.
NOTICE
Risk of collision
If the signal ERROR is not monitored in the PLC or the measuring cycles, the falling edge
(STATUS) must be used compulsorily for the measuring input.
