BLUM IF59-A2 User Manual

V3A | 08/2018
37
© by Blum-Novotest
Setup radio system
Fig. 5-2
1. Create operating mode with which a radio probe is operated (here: TC1)
2. Start pairing with: signal AUX = high
Select probe which should be paired:
Hold the magnetic pin on SET, until the LED Status shines blue
(approx. 2 sec.).
3. Signal Stat1 = high:End of pairing
Signal
Error = high:Pairing successful
Signal
Error = low:Pairing failed
4. To terminate the action, reset signals TC / DUO / BG / TWIN.
5. Reset signal AUX.
Stat1
Error
Stat1
AUX
Mode TC
1. Mode 2. Start 3. o.k. 5. End4. Failure
Mode DUO
Mode BG
Mode TWN
H
L
H
L
H
L
H
L
H
L
H
L
H
L
H
L
o
ff
SETMODE
7
