BLUM MINIPRESS User Manual

48
L
Appendix
!
Technical Data
1. General data
• Voltage: See type plate
• Power supply: See type plate
• Connected load
motor 1.1 kW
• rpm See type plate
• Compressed air: 80 - 100 psi
• Air consumption: 1.5 liters per
cycle
Important:
Provide a 16 A backup fuse
breaker.
2. Weight and measurements
• Weight: m = 81 lbs (37 kg)
• Dimensions:
H = 27-15/16" (710 mm)
W = 24" (610 mm)
D = 29-15/16" (760 mm)
3. Maximum thickness of workpiece
• Drilling only 1-3/4“ (45 mm)
• Insertion of fittings
depending on fitting max. 13/16“
max. (20 mm)
max. 1-1/4“
max. (32 mm)
4. Maximum drilling distance
• Drilling distance
center spindle: (-3/16“) - 2-1/2“
(-5mm) - 64 mm
5. Maximum drilling diameter
• Maximum drilling
diameter 1-3/8“ (35 mm)
6. Accessories
• For accessories see BLUM catalog
%$0,1,35(66)$,G1US $0
