BLUM TANDEM plus BLUMOTION 563F Installation Instructions

TANDEM plus BLUMOTION
Subject to technical modifications without notice. © 2015 Blum Inc.
Dimensions in millimeters (inch equivalents as noted)
6
Bottom mounting specifications
Top view
Millimeter to inch conversion chart
1 1.5 2 3 4 5 5.5 6 7 8 9 9.5 10 11 12 13 13.5 14 15 16 17 17.5 18 19 20 20.5 21 22 23 24 24.5 25.4
1
/
32
1
/
16
3
/
32
1
/
8
5
/
32
3
/
16
7
/
32
1
/
4
9
/
32
5
/
16
11
/
32
3
/
8
13
/
32
7
/
16
15
/
32
1
/
2
17
/
32
9
/
16
19
/
32
5
/
8
21
/
32
11
/
16
23
/
32
3
/
4
25
/
32
13
/
16
27
/
32
7
/
8
29
/
32
15
/
16
31
/
32
1
INST-TDM563F 05.15
3 (1/8")
X
67 (2-5/8")
9 (11/32")
Y
Z
9 (11/32")
TANDEM plus
BLUMOTION
Drawer
length
Minimum inside
cabinet depth
XYZ
563F5330B
533 (21") 557 (21-15/16") 448 (17-5/8") 15.5 (5/8") 22.5 (7/8")
563F4570B
457 (18") 480 (18-29/32") 378 (14-7/8") 15.5 (5/8") 22.5 (7/8")
563F3810B
381 (15") 404 (15-29/32") 319 (12-9/16") 15.5 (5/8") 22.5 (7/8")
Attachment specifications
Depth adjustment specifications
Side view
Mount each runner using at least two of the elongated holes. Install the drawer to check the
position of the drawer front.
Remove the drawer, loosen screws and make adjustments if necessary, ±4.5 (3/16").
Tighten the screws, verify the drawer front position and finish mounting the runners using the
screw locations indicated by the orange dots.
TANDEM plus
BLUMOTION
AB
563F5330B
244.5 (9-5/8") 500.5 (19-23/32")
563F4570B
244.5 (9-5/8") 436.5 (17-3/16")
563F3810B
148.5 (5-27/32") 340.5 (13-13/32")
563F3050B
148.5 (5-27/32") 244.5 (9-5/8")
563F2290B10
116.5 (4-19/32") 212.5 (8-3/8")
Rear attachment options for face frame applications
Front view
NOTE:
Use at least three 606N or 606P installation screws for 295.3750.01 or 295.3700.2x
12
face frame rail
face frame stile
16 32
14 (9/16")
(1-1/4")
(5/8")
(3/32")
2
21
(13/16")
(15/32")
17.5
32
(1-1/4")
(11/16")
16 (5/8")
face frame rail
face frame stile
5 (3/16")
4 (5/32")
39.5 (1-9/16")
face frame stile
face frame rail
16
(5/8")
32
(1-1/4")
Ø
8
3.2 (1/8")
face frame stile
face frame rail
9 (11/32")
37
(1-15/32")
6.5 (1/4")
2 (3/32")
19
(3/4"
)
40 (1-9/16")
9 (11/32")
295.6410
Plug-in socket, non-handed
295.3700.2x
For 563F2290B10, non-handed
295.3750.01
Rear mounting bracket,
non-handed
295.6400
Screw-on socket, non-handed
A
B
20.5 (13/16")
setback
