3.11 Drive shaft
Removal
Before the drive shaft can be loosened, the
cam must be removed.
Remove the drive shaft(1) by hand from
the inside. If necessary replace defective
O-rings(2 & 3).
Mounting
Apply a small amount of oil to the drive shaft’s
surface and O-rings.
Install the drive shaft and press into place.
