BLX v100 positioner - 6 Technical Info; Specifications

6.1 Specifications
V100P V100E
Input range: 3-15 PSI (20-100kPa) 4-20 mA (Ri<250ohms)
Supply pressure: <145 PSI (<1MPa) 21.8-145 PSI (0.15-1MPa)
Linearity error: <0.7% f.s <1.0% f.s
Hysteresis: <0.4% f.s <0.6% f.s
Repeatability: <0.3% f.s <0.5% f.s
Pressure Gain:
@87 PSI (600kPa) 750 P
out
/ P
in
750 P
out
/ P
in
acc. to ISA S75.13 49 %P
out
/ %P
in
49 %P
out
/ %P
in
Air Capacity: SCFM (SLPM) SCFM (SLPM)
@29 PSI (200kPa) 9.5 (270) 9.5 (270)
@87 PSI (600kPa) 28.3 (800) 28.3 (800)
@145 PSI (1MPa) 47.1 (1350) 47.1 (1350)
Bleed Rate: SCFM (SLPM) SCFM (SLPM)
@29 PSI (200kPa) 0.18 (5) 0.2 (5.7)
@87 PSI (600kPa) 0.53 (15) 0.6 (17.0)
@145 PSI (1MPa) 0.88 (25) 1.0 (28.3)
Weight: 3.5 lbs (1.6kg) 3.8 lbs (1.7kg)
Weight with gauges: 4.0 lbs (1.8kg) 4.2 lbs (1.9kg)
Temp range: -40° to +185° Fahrenheit
-40° to +85° Celsius
Air connectors: 1/4” NPT (optional G threads)
Gauges: 1/8” NPT (optional G threads)
Cable entry: 1/2” NPT (optional M20x1.5 or PG 13.5)
Ingress & corrosion protection: NEMA 4X and IP66
Coating: Powder Polyester
Options: Feedback Spring for 6-30 PSI (40-200kPa) input signal.
Gauges.
Pilot Valves:
W1 Low Gain-Medium Flow-Low Bleed
for better stability and lower bleed.
Pressure gain @87 PSI =300
Bleeds approx. 33% < than W3
Air capacity =10% < W3 (above chart)
W2 High Gain-High Flow-High Bleed
For faster response and better accuracy.
Pressure gain @87 PSI >1000
Bleeds approx. 33% > than W3
Air capacity = W3 (above chart)
W3 Medium Gain-High Flow-Medium Bleed
For “average” capacity and bleed
Standard Pilot Assembly
Specifications shown in above chart
