4 Shield Bottom 1
5 Humidifier Clip 1
6 Humidifier Locker 1
7 Humidifier Fixing 1
8 Filter Cover 1
9 Shield Back 1
10 Outlet 1
11 PCBA Fixing 2
12 Infrared Window 2
13 Panel 1
14
Humidifier Outer
Shield
1
