Service Manual for RESmart
®
BPAP V1.1
15/18
2
Put spring on each of three poles on heater
plane.
3
Assembly the scaleboard on the heater
plane and fix by screw (3mm*8mm).
Scaleboard
4
As per Table 3, assembly heater PCBA and
wires.
5 Put on light window.
6 Assembly the inner and outer shield.
7 Fix on screw (M3*10mm).
Screw
Appendix B:
Spare Part Configuration
S/N Name Qty Figure
1 Shield Cover 1
2 Handle 1
3 Handle Fixing 2
