PHERAstar FS Operating Manual BMG LABTECH
8/26 0471B0001A 2009-09-22
2.2 Back of PHERAstar FS
Figure 4: Back of PHERAstar FS
Figure 5: Back of PHERAstar FS
Main power on/off switch
Fan
Air inlet
Miscellaneous labeling such as serial
Number, CE-marking, and voltage
information
Main power on/off switch
USB connection to PC
RS-232 connection to Stacker
USB connection to PC
