T.O. BMS1F-16CM-1 BMS 4.34 Change 2.00
BMS 4.34 Dash 1
© Red Dog 2012-2019 Page: 232
Negative G flight with both reservoir tanks full is limited to:
• AB thrust: 10 seconds.
• MIL thrust or below: 30 seconds.
• Negative flight should be avoided with a low fuel condition, or when the
ENG FEED knob is out of NORM.
Maximum airspeed (VNE): 800 Kts sea level to 30000 feet & M2.05 above 30000 ft.
Max speed may be further reduced according to stores carried.
Maximum airspeed with Gear Down: 305 Kts.
Maximum airspeed for AAR door opening: 400 Kts.
Max Gross Weight: 48000 lbs.
Centre of Gravity Limitations:
• Generally CG is always within limits unless the red portion of the AL Fuel Quantity needle is
visible.
• Without external tanks the most aft CG occurs with 2000 lbs of internal fuel remaining.
• With external tanks the most aft CG happens when the external fuel tanks have just emptied.
Crosswind limits: 25 kts.
