OZONE ANALYZER BMT 964 Manual, Rev. 04/2021
13
Zeroing the Instrument from the Front Panel
If ozone concentration is shown on the display and the ZERO button is pushed, the instrument
displays the question:
Zeroing: Are you sure?
Due to the fact that zeroing with ozone would lead to wrong measurement results, this question
gives the user the opportunity to stop. This can be done by pressing the button BACK. In case
there is really no ozone present in the cuvette, the ZERO button may be pressed again, after
which zeroing starts. Further information about zeroing the BMT 964 can be found on page 23.
The Menu View Parameters
In the menu View Parameters the configuration of the BMT 964 can be viewed, but it cannot
be changed.
Units Alarms RS-232
Gas
Parameters
Time/Date Other Param.
See next
Page
Time Date
Norm.
Temperature
Norm.
Pressure
Mol. Weight
Baudrate Timed/Polled Time Interval
High Alarm Low Alarm
Relays Open/
Close
Enable/
Disable
Threshold Latching
Enable/
Disable
Threshold Latching
Ozone Pressure
Menu View ParametersSCROLL
ENTER
BACK
The following parameters are shown:
Units
Unit of ozone concentration
Unit of pressure
Alarms
Activation, thresholds, latching, closing or opening of Alarm Relays
RS-232
Baud rate, periodic transmission or polling, time interval of periodic transmission
Gas-Parameters
nature of the carrier gas: air or oxygen (incl. PSA oxygen)
Time / Date
To Next Page
