USB port
General information
Follow the information regarding the connection
of mobile devices to the USB port in the section
on USB connections.
Additional information:
USB connections, refer to page 79.
In the center armrest
A USB port is located in the center armrest.
Properties:
▷ USB port Type C.
▷ For charging of mobile devices.
▷ Charge current: max. 3 A.
▷ For data transfer.
Steptronic transmission: in the
center console
NOTICE
Objects in the storage compartment, e.g., large
USB connectors, may block or damage the
cover when it is being opened or closed. There
is a risk of damage to property, among other
potential damage. Make sure that the area of
movement of the cover is clear while opening
and closing it.
Push the cover forward until it engages.
A USB port is located in the center console.
Properties:
▷ USB port Type A.
▷ For charging mobile devices and for data
transfer.
▷ Charge current: max. 1.5 A.
In the rear center console
Two USB ports are located in the center console
in the rear passenger compartment.
Properties:
▷ USB port Type C.
▷ For charging of mobile devices.
Seite 291
Interior equipment
CONTROLS
291
