NOTICE
During opening, the trunk lid pivots back and
up. There is a risk of damage to property,
among other potential damage. Make sure that
the area of movement of the trunk lid is clear
during opening and closing.
Opening
Press and hold the button on the vehi‐
cle key for approx. 1 second.
Switching pathway lighting on
Press and hold the button on the vehi‐
cle key for approx. 1 second.
It is possible to adjust the duration of the path‐
way lighting feature.
Additional information:
Pathway lighting, refer to page 173.
Replacing the battery
NOTE
Improper batteries in the vehicle key can dam‐
age the vehicle key. There is a danger of dam‐
age to property. Always replace the discharged
battery with a battery with the same voltage,
the same size and the same specification.
1.
Remove the integrated key from the vehicle
key.
Integrated key, refer to page 95.
2. Place the integrated key underneath the bat‐
tery compartment cover, arrow 1, and lift the
cover with a lever movement of the
integrated key, arrow 2.
3. Push battery in arrow direction using a
pointed object and lift it out.
4. Insert a type CR 2032 3V battery with the
positive side facing up.
5. Press the cover closed.
6. Push the integrated key into the vehicle key
until the integrated key engages.
Have old batteries disposed of by a deal‐
er’s service center or another qualified
service center or specialist workshop or
take them to a collection point.
Additional vehicle keys
Additional vehicle keys are available from a serv‐
ice center or another qualified service center or
repair shop.
Loss of vehicle keys
A lost vehicle key can be blocked and replaced
by a dealer’s service center or another qualified
service center or repair shop.
Seite 84
CONTROLS
Opening and closing
84
Online Edition for Part no. 01405A2C7F8 - II/21
