Insert bulb 1, making sure that
tab 2 is correctly seated.
Engage spring retainer 3 in the
catches.
Connect connector 1.
Install cover 1 or cover 2, as
applicable.
Installing side panel ( 107).
Replacing bulb for
number-plate light
Switch off operational readi-
ness.
Pull number-plate light bulb 1
out of the light housing.
Remove the bulb from the
socket.
9
105
z
Maintenance
