Maintenance and care
• Slip the silencer onto the
exhaust elbow
• Align hole 1 in clamp with
locating mark 2 on the
silencer
• Position the silencer against
the frame and hand-tighten
the securing screw
• Tighten the clamp to the
specified tightening torque
• Tighten the securing screw
on the frame to the specified
tightening torque
• Remove the auxiliary stand
d Warning:
Always have the security of
the fasteners checked by a
specialist workshop, prefera-
bly an authorised BMW mo-
torcycle dealer.
X Tightening torque:
Wheel nut 1 ................. 160 Nm
Clamp ........................... 55 Nm
Securing screw,
silencer to frame ........... 41 Nm
Installing the rear wheel
1
2
