N55 Engine
Index Explanation
1
Instrument cluster
2
Central Gateway Module
3
Coolant level switch
4
Coolant temperature sensor
5
Electric fan
6
Mechanical air flap control
7
Electric air flap control
8
Digital Motor Electronics
9
Front power distribution box
10
Junction box electronics
11
Junction box
12
Electric fan relay
14
Rear power distribution box
15
Electric fan relay (only for 850 Watt and 1000 Watt electric fan)
