94
N55 Engine
N55, crankshaft sensor with multipole sensor wheel
Ignition Coil
New ignition coils have been developed for the N55 engine. The ignition coils have
improved electromagnetic compatibility and are sturdier. The insulation has been rein-
forced with silicone and a metal collar shielding compared to the coils used on previous
engines. See the Service Information section of this training material for more details.
Always remove the ignition coils before opening the fuel system. Gasoline may
damage the silicone insulation on the coils which may lead to arcking and sub-
sequent engine misfiring.
Index Explanation
1
Connector
2
Dust seal
3
Sensor
CAUTION!!!
