Transmitter Setup
Spektrum DX6i
SETUP LIST
SYSTEM LIST
ADJUST LIST
ADJUST LIST
POS-0POS-0 POS-1
Spektrum DX7/DX7se
Model Type Reverse Swash Type Timer
HELI THRO—N CCPM 120 Type—Down
AILE—R Time—4:00
ELEV—N
Switch—
Trainer
RUDD—R
GYRO—N
PITC—N
Model Type Swash Type Input Select
HELI
3 Servo 120
Degree CCPM
AUX2 GEAR
INH GYRO
D/R Expo
AILE 0 100% 15
ELEV 0 100% 15
RUDD 0 100% 0
AILE 1 85% 10
ELEV 1 85% 10
RUDD 1 85% 0
AUTO D/R EXP
NORM INH
ST-1 INH
ST-2 INH
HOLD INH
AILE ELEV RUDD
EXP 15% EXP 15% EXP LIN
D/R 100% D/R 100% D/R 100%
AILE ELEV RUDD
EXP 10% EXP 10% EXP LIN
D/R 85% D/R 85% D/R 85%
TRAVEL ADJUST
THRO 100%
AILE 100%
ELEV 100%
RUDD 80%
GYRO 100%
PITC 100%
SWASH MIX
AILE -91%
ELEV 91%
PITC 64%
SWASH MIX
AILE 68%
ELEV -68%
PITC 55%
TRAVEL ADJUST
THRO AILE
H 100% L 100%
L 100% R 100%
ELEV RUDD
D 100% L 80%
U 100% R 80%
GEAR PIT
+ 100% H 100%
- 100% L 100%
AUX2
+ 100%
- 100%
SUB-TRIM
THRO 0
AILE 0
ELEV 0
RUDD 0
GYRO 0
PITC 0
SUB-TRIM
THRO 0
AILE 0
ELEV 0
RUDD 0
GEAR 0
PITC 0
AUX2 0
GYRO
Rate SW-F. Mode
0 72.0% NORM 0
1 68.0% STUNT 1
GYRO SENS
AUTO F. MODE
RATE NORM 0
0 81.0% STNT 1
1 77.0% HOLD 0
THRO HOLD
HOLD POS 0.0%
SW RUDD D/R
TIMER
DOWN-T 4:00
REVERSING SW
THRO AILE ELEV RUDD GEAR PIT AUX2
N N N R N R N
THRO CUR
L 2 3 4 H
NORM 0% 60% 80% 80% 80%
STUNT 100% 100% 100% 100% 100%
HOLD 10% 10% 10% 10% 10%
THRO CURVE
L 1 2 3 H
NORM 0% 60% 80% 80% 80%
ST-1 100% 100% 100% 100% 100%
ST-2 100% 100% 100% 100% 100%
PITC CUR
L 2 3 4 H
NORM 30% 40% 50% 75% 100%
STUNT 0% 25% 50% 75% 100%
HOLD 0% 25% 50% 75% 100%
PITCH CURVE
L 1 2 3 H
NORM 30% 40% 50% 75% 100%
ST-1 0% 25% 50% 75% 100%
ST-2 0% 25% 50% 75% 100%
HOLD 0% 25% 50% 75% 100%
Program your transmitter before attempting to bind or fly the helicopter. TransmitterprogrammingvaluesareshownbelowfortheSpektrumDX6i,
DX7/DX7se,DX7sandDX8.TheSpektrummodellesforAirWare™transmittersarealsoavailablefordownloadontheSpektrumCommunitywebsite.
CAUTION:WhenusingaFutabatransmitterwithaSpektrumDSMmodule,youmustreversethethrottlechannelandrebind.RefertoyourSpektrum
module manual for binding and failsafe instructions. Refer to your Futaba transmitter manual for instructions on reversing the throttle channel.
