BNF Blade 500 3D - Spektrum DX7 s Transmitter Setup

7
EN
SWASHPLATE
AILE 79%
ELEV -79%
PITC 55%
EXP INH
SYSTEM LIST
FUNCTION LIST
Spektrum DX7s
SERVO SETUP
TRAVEL SUB TRIM REVERSE
THROTTLE 100 100 THROTTLE 0 THROTTLE N
AILERON 100 100 AILERON 0 AILERON N
ELEVATOR 100 100 ELEVATOR 0 ELEVATOR N
RUDDER 80 80 RUDDER 0 RUDDER R
GYRO 100 100 GYRO 0 GYRO N
PITCH 100 100 PITCH 0 PITCH R
AUX2 100 100 AUX2 0 AUX2 N
D/R AND EXPO
POS D/R D/R EXPO SW
AILERON 0 100 100 15 AILE D/R
AILERON 1 85 85 10 AILE D/R
ELEVATOR 0 100 100 15 ELEV D/R
ELEVATOR 1 85 85 10 ELEV D/R
RUDDER 0 100 100 0 RUDD D/R
RUDDER 1 85 85 0 RUDD D/R
GYRO
SW F Mode
CH Gear
NORMAL/POS 0 55
STUNT 1/POS 1 53
HOLD 55
TIMER
MODE Countdown
TIME 4:00 Tone/Vibe
START Throttle Out
POS 25
THROTTLE CURVE
LOW 25% 50% 75% HIGH EXPO
N 0 60 80 80 80 INH
1 100 100 100 100 100 INH
H 0 0 0 0 0 INH
TAIL CURVE
LOW 25% 50% 75% HIGH EXPO
N 0 0 0 0 0 INH
1 0 0 0 0 0 INH
H 0 0 0 0 0 INH
PITCH CURVE
LOW 25% 50% 75% HIGH EXPO
N 30 40 50 75 100 INH
1 0 25 50 75 100 INH
H 0 25 50 75 100 INH
Model Type Swash Type Switch Select F Mode Setup Warnings Frame Rate
Helicopter
3 Servos
120
All Switches
INH
Flight Mode — F
Mode
Throttle —Over 10 11ms
Hold — Hold Stunt 1—Active DSMX
Hold—Active
Alarm—Tone/Vibe
THROTTLE CUT
INHIBIT
GOVERNOR
SW-INHIBIT
Transmitter Setup
