BNF Blade 500 3D - Spektrum DX8 Transmitter Setup

8
EN
SYSTEM LIST
FUNCTION LIST
Spektrum DX8
SERVO SETUP
TRAVEL SUB TRIM REVERSE SPEED
THROTTLE 100 100 THROTTLE 0 THROTTLE N THROTTLE NORM
AILERON 100 100 AILERON 0 AILERON N AILERON NORM
ELEVATOR 100 100 ELEVATOR 0 ELEVATOR N ELEVATOR NORM
RUDDER 80 80 RUDDER 0 RUDDER R RUDDER NORM
GYRO 100 100 GYRO 0 GYRO N GYRO NORM
PITCH 100 100 PITCH 0 PITCH R PITCH NORM
AUX2 100 100 AUX2 0 AUX2 N AUX2 NORM
AUX3 100 100 AUX3 0 AUX3 N AUX3 NORM
D/R AND EXPO
POS D/R D/R EXPO SW
AILERON 0 100 100 15 AILE D/R
AILERON 1,2 85 85 10 AILE D/R
ELEVATOR 0 100 100 15 ELEV D/R
ELEVATOR 1,2 85 85 10 ELEV D/R
RUDDER 0 100 100 0 RUDD D/R
RUDDER 1,2 85 85 0 RUDD D/R
GYRO
SW F Mode
CH Gear
NORMAL/POS 0 55
STUNT 1/POS 1 53
STUNT 2/POS 2 53
HOLD 55
TIMER
MODE Countdown
TIME 4:00 Tone/Vibe
START Throttle Out
POS 25
THROTTLE CURVE
LOW 25% 50% 75% HIGH EXPO
N 0 60 80 80 80 INH
1 100 100 100 100 100 INH
2 100 100 100 100 100 INH
H 0 0 0 0 0 INH
TAIL CURVE
LOW 25% 50% 75% HIGH EXPO
N 0 0 0 0 0 INH
1 0 0 0 0 0 INH
2 0 0 0 0 0 INH
H 0 0 0 0 0 INH
PITCH CURVE
LOW 25% 50% 75% HIGH EXPO
N 30 40 50 75 100 INH
1 0 25 50 75 100 INH
2 0 25 50 75 100 INH
H 0 25 50 75 100 INH
Model Type Swash Type Switch Select F Mode Setup Trim Step Warnings Frame Rate
Helicopter 3 Servos 120 All Switches INH Flight Mode — F Mode THR 5 Throttle —Over 10 11ms
Hold — Hold AIL 5 Stunt 1—Act DSMX
ELE 5 Stunt 2—Act
RUD 5 Hold—Act
R TRIM 5 Alarm—Tone/Vibe
L TRIM 5
TYPE Common
THROTTLE CUT
INHIBIT
GOVERNOR
INHIBIT
Transmitter Setup
SWASHPLATE
AILE 79%
ELEV -79%
PITC 55%
EXP INH
E-RING INH
