24
SoundExpression
2.4.3 Attaching a Joystick/MIDI Device
1. If you are connecting a joystick only, use a 15-pin cable with D-sub
connector. NOTE: You may also attach two joysticks providing you
have a 15-pin “Y” cable.
2. If you are connecting a MIDI-compatible keyboard synthesizer as well,
use a MIDI cable to make connections as shown below. Connecting
external audio/game devices is complete.
123
123
123
123
123
JOYSTICK WITH IBM PC
COMPATIBLE 15-PIN D-SUB
CONNECTOR (OPTIONAL)
IN
OUT
MIDI CABLE
JOYSTICK WITH IBM PC
COMPATIBLE 15-PIN D-SUB
CONNECTOR (OPTIONAL)
KEYBOARD SYNTHESIZER
(OPTIONAL)
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
SPK
L-OUT
L-IN
MIC
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
SPK
L-OUT
L-IN
MIC
