53
Appendix B: Configuration Settings
Sound Blaster CD-ROM
Addresses: 220, 240 Addresses: 320, 330, 340,
IRQ: 5, 7, 10 360, (170/IDE only)
DMA: 0, 1, 3 IRQ: 5, 7, 9, 10, 11, (15/IDE only)
Windows Sound System IDE CD (only)
Addresses: 530, E80, F40, 604 Address: 170
IRQ: 7, 9, 10, 11 IRQ: 15
DMA: 0, 1, 3
MPU-401 Interface MODEM Addresses
Addresses: 300, 310, 320, 330 COM1, 2, 3, 4
IRQ: 2/9, 5, 7,10 IRQ3, 4, 5, 7
Default Configuration
The SE1440 supports both Sound Blaster as well as Windows Sound
System applications. After drivers are installed and configured, the card is
in Sound Blaster mode when in DOS. It switches to Windows Sound
System mode when you start Windows. The default configuration for the
board is as follows:
Mode: Sound Blaster Modem
Interrupt: IRQ5 IRQ3
DMA Channel: DMA1 NA
I/O Port Address: 220h 2F8h (COM2)
CD-ROM interface: None NA
Configuration Settings
